Planning to charge your EV in Europe from a standard wall socket? A Type 2 to Schuko cable is the link between your car’s Type 2 inlet and the CEE 7/4 Schuko sockets you’ll find in most European homes, holiday rentals, and some campsites. It’s slow, typically 2.3 kW to 3.7 kW, but it can add enough overnight range to keep you moving. Here’s everything you need to know before you buy one, including a few things most guides miss.
What Is a Type 2 to Schuko Cable?
A Type 2 to Schuko cable connects your EV’s standard Type 2 inlet to the CEE 7/4 Schuko sockets found across most of continental Europe. The cable includes an IC-CPD (an in-cable control and protection device required by IEC 62752) that monitors earth continuity and prevents unsafe charging.
- Schuko end (CEE 7/4): 2 round pins 4.8mm dia, 19mm spacing, grounding clips on sides; Type 2 end: 7-pin IEC 62196-2 female; IC-CPD box in cable (IEC 62752): earth monitor, overcurrent protection, pilot signal; Cable rating: 10A or 16A, 230V, 2.3kW or 3.7kW
One thing most articles get wrong: the Schuko plug is not simply a “two-pin” plug. The CEE 7/4 standard specifies two round pins, 4.8 mm in diameter and spaced 19 mm apart, but earth (ground) is provided not by a third pin but by two metal clips on the sides of the plug body. These side earth clips engage with corresponding contacts inside a CEE 7/3 Schuko socket, or the side openings of a French or Belgian CEE 7/5 socket. Remove those side clips from your mental picture and you have an unearthed, unsafe plug. That is exactly what a bare Schuko adapter is when used without an IC-CPD.
The Type 2 end of the cable uses the IEC 62196-2 seven-pin connector. This is the same socket inlet found on every EV sold in the UK since around 2018, and the same standard used across the EU. That socket on the side of your car is already Schuko-compatible in principle: you simply need the right Mode 2 cable to bridge the gap safely.
Partway along the cable you will see a box, typically similar in size to a large power bank. That is the IC-CPD. We cover its importance fully in its own section below, but the short version is this: without it, the cable is not a Mode 2 product, and it is not safe for EV charging.
It is worth setting expectations at this point. This cable is a slow-charging solution. It is not a replacement for a wallbox, a public rapid charger, or even a Mode 3 Type 2 post. What it is: a capable overnight charging option when you are staying somewhere in continental Europe with no better option available. Used sensibly, a Type 2 to Schuko cable can top up enough range each night to keep your European trip moving without anxiety.
Key specifications at a glance:
| Attribute | Value |
|---|---|
| EV socket end | IEC 62196-2 Type 2 female |
| Wall socket end | CEE 7/4 (Schuko) |
| Pin configuration | 2 round pins (4.8 mm dia, 19 mm spacing) + earth clips on plug sides |
| Current rating | 10 A typical; 16 A where circuit supports it |
| Power output | 2.3 kW at 10 A / 3.7 kW at 16 A |
| Charging speed | ~8 miles/hr at 10 A; ~15 miles/hr at 16 A |
| Applicable region | Continental Europe; not for UK use |
| Protection standard | IC-CPD per IEC 62752 |
Charging Speed and Current
At a typical 10 A Schuko socket, a Type 2 to Schuko cable delivers 2.3 kW, adding around 8 miles of range per hour. On a 16 A circuit you get 3.7 kW and roughly 15 miles per hour. Overnight at 10 A covers around 80 miles, enough for most day’s driving in Europe.
- 10A / 230V / 2.3kW / ~8 miles of range per hour / typical EU domestic Schuko circuit; 16A / 230V / 3.7kW / ~15 miles per hour / Schuko circuit with 16A breaker (less common); Comparison: Mode 3 public Type 2 post (11kW, 22kW) / much faster but needs no Schuko cable; Note: Overnight charge from 10A adds ~80 miles (10 hrs × 8 miles/hr)
The 10 A figure deserves more explanation than most articles give it. Most EU domestic Schuko circuits are protected by a 10 A, 13 A, or 16 A circuit breaker. The rating in your specific holiday rental, gîte, or host’s garage may not be what you expect. EV charging draws sustained, continuous current for many hours, which is a very different load profile to the intermittent draws that residential socket circuits are typically designed for. A 10 A continuous draw is within spec, but if the circuit is shared with other appliances (a fridge, a kettle used at the same time in the evening) or if the breaker is already warm from earlier use, it may trip.
We always recommend starting at 10 A (2.3 kW) and only increasing to 16 A if the property owner or host can confirm that the specific socket circuit supports sustained 16 A load. Many cheaper holiday rentals in Spain, Portugal, and southern France have older wiring where even 10 A sustained draw can cause problems. When in doubt, charge at 10 A and wake up to a fuller battery rather than a tripped fuse.
For context: a public Mode 3 Type 2 charging post delivers between 11 kW and 22 kW, five to ten times more power than a Schuko socket. The Schuko cable is not a substitute for planning your public charging stops; it is a safety net for evenings when nothing else is reachable.
Where You Can (and Can’t) Use It
A Type 2 to Schuko cable cannot be used in the UK. Schuko plugs (CEE 7/4) do not fit UK BS 1363 sockets, and using a Schuko-to-UK adapter for EV charging is unsafe and non-compliant. For UK home charging from a regular socket, you need a separate granny charger with a UK BS 1363 plug.
This restriction surprises some buyers, so we want to be direct about it. If you return from a European trip and think “I can just plug this in at home with a travel adapter”, please do not. A Schuko-to-UK adapter bypasses the safety chain entirely. The IC-CPD inside the cable is designed around the earthing arrangement of a CEE 7/3 Schuko circuit. Routing it through a passive adapter into a UK BS 1363 socket does not recreate that arrangement, the cable is not certified to UK standards, and the result is a non-compliant, potentially unsafe setup.
Schuko sockets (CEE 7/3) are standard across Germany, Austria, the Netherlands, Spain, Portugal, Sweden, Norway, and most of continental Europe. The CEE 7/4 plug also fits French and Belgian CEE 7/5 sockets: the Schuko’s side earth clips do not engage with the French socket, but the two power pins connect correctly and earth is made through the socket’s central pin instead. This makes France and Belgium compatible destinations for a Type 2 to Schuko cable, which is useful to know given how many UK drivers travel through those countries en route to or from Germany and beyond.
However, the Schuko plug does not fit Swiss Type J (SEV 1011), Danish Type K (DS 60884), or most Italian Type L (CEE 7/11) sockets. If your trip includes Switzerland, Denmark, or Italy as significant charging stops, you may need country-specific adapters or cables. Always check the socket standard used at your specific accommodation before departing, especially if you are relying on charging access rather than treating it as a backup.
A practical tip for longer European tours: search for your accommodation on a mapping tool that shows EV charging points in the vicinity, and treat the Schuko cable as your overnight fallback rather than your primary plan. Pairing the cable with good route planning across public Mode 3 networks will give you a much more relaxed trip than relying on Schuko charging alone.
IC-CPD: Why the Box in Your Cable Matters
The IC-CPD box built into every compliant Type 2 to Schuko cable is not an optional extra. IEC 62752 requires it in every Mode 2 EV charging cable. It monitors earth continuity, detects overcurrent, and sends a pilot signal before allowing current to flow. A bare Schuko adapter without an IC-CPD provides none of these protections and is not safe for EV charging.
IEC 62752 is the international standard that governs Mode 2 in-cable control and protection devices. The three core functions are: continuous earth-continuity monitoring (the IC-CPD cuts power the moment it detects a fault with the protective earth connection); overcurrent protection (it will interrupt the circuit if current exceeds the rated limit); and control pilot signalling (a communication between the cable and your car’s on-board charger that must confirm a complete, safe circuit before EV charging current flows at all). Your car simply will not start drawing charge without that pilot signal from the IC-CPD.
A bare Schuko adapter (the cheap, plug-shaped item sometimes described as a “Schuko EV adapter” or “charging adapter”) is a passive connector with no electronics. There is no earth monitoring, no overcurrent protection, and no pilot signal. Your car may refuse to charge through it because the pilot is absent. Or, with an older or less sophisticated vehicle, it may begin drawing current with no protection in place. Neither outcome is acceptable for hours of overnight charging.
When evaluating any Type 2 to Schuko product, look for explicit mention of IC-CPD compliance and IEC 62752. If the product listing describes only a plug conversion with no reference to a control box, that is not a Mode 2 cable.
The IC-CPD also communicates with your car throughout the charging session, not just at the start. If you unplug an appliance elsewhere on the circuit mid-charge and the breaker trips, the IC-CPD detects the loss of earth and stops the session safely, rather than leaving a live connector exposed. This continuous monitoring is what makes a compliant Mode 2 cable meaningfully safer than any passive adapter, and why IEC 62752 exists as a mandatory standard rather than a voluntary guideline.
Campsites and the Commando Alternative
If you are planning to charge at EU campsites rather than private accommodation, there is one more important thing to know: many EU campsites do not use Schuko sockets at their hook-up points at all.
The blue socket post on a campsite pitch, the “hook-up”, very often uses a blue IEC 60309 16 A industrial Commando connector, not a domestic Schuko socket. IEC 60309 Commando connectors are the same blue round three-pin plugs used on UK caravan sites and motorhome pitches. They are specifically designed for outdoor, sustained-load use and are common across EU campsite infrastructure precisely because they are more robust than Schuko for that purpose.
Before you set off, contact your specific campsite and ask which socket standard their electric hook-up points use. Do not assume Schuko. Some sites use Schuko at older pitches and Commando at newer ones. A growing number of campsites have begun installing dedicated EV charging posts, which is a separate matter again. Those will typically take a Mode 3 Type 2 cable, which you may already have from your car.
If you are touring multiple campsites across different countries, carrying both a Type 2 to Schuko cable and a separate Type 2 to Commando (IEC 60309) cable gives you maximum flexibility. Our full guide to charging your EV in Europe covers campsite hook-up standards by country, what to do when you cannot find a charger, and how to plan a European road trip around charging availability.
What to Look For When Buying
The non-negotiable requirement is IEC 62752 compliance. This confirms that the cable’s IC-CPD has been designed and tested to the international Mode 2 standard. It should be stated explicitly in the product description or specification sheet, rather than merely implied by a picture of the cable with a box on it.
Beyond compliance, consider these practical factors:
Cable length. A 5 m cable is suitable for most holiday rental and private driveway situations. Some drivers prefer 8 m or 10 m for added flexibility, particularly when the socket is on one side of a garage and the car inlet on the other.
Current rating. A 10 A cable covers the majority of real-world situations. A 16 A cable offers more flexibility on circuits that support it. Some cables include a manual selector dial; others negotiate with the circuit automatically. For most drivers, a good-quality 10 A cable is the sensible starting point.
IP rating. Look for IP55 or better if you will be using the cable outdoors: at campsites, in open driveways, or in wet conditions.
Warranty. We provide a minimum two-year warranty on all cables stocked at EV Cable Hubed lines.
We supply Type 2 to Schuko cables with IEC 62752-compliant IC-CPDs, a minimum two-year warranty, 30-day hassle-free returns, and carbon-neutral DPD shipping, free on orders over £150. Every cable we stock has been selected for compliance and cable quality, not just price.
For UK home slow charging, meaning charging from a regular three-pin socket at your own property, a Schuko cable is entirely the wrong product. What you need is a granny charger: a Mode 2 cable with a UK BS 1363 plug at one end and a Type 2 connector at the other. The slow-charging principle is the same, but the wall plug is designed and certified for UK sockets. Our guide to granny chargers and emergency backup charging explains when a granny cable is useful, how long it takes to charge, and what to look for when buying.
Frequently Asked Questions
What is a Type 2 to Schuko cable?
A Type 2 to Schuko cable is a Mode 2 EV charging cable with a Type 2 (IEC 62196-2) connector at one end for your car and a CEE 7/4 Schuko plug at the other for a continental European wall socket. It includes a built-in IC-CPD safety device (per IEC 62752) and typically delivers 2.3 kW to 3.7 kW, enough for overnight charging when faster options are not available.
How fast does a Type 2 to Schuko cable charge?
At 10 A (the limit on most EU domestic Schuko circuits) you get 2.3 kW, adding roughly 8 miles of range per hour. On a 16 A circuit the cable delivers 3.7 kW and about 15 miles per hour. An overnight charge of 10 hours at 10 A adds approximately 80 miles, sufficient for a day’s driving across much of Europe.
Can I use a Schuko cable in the UK?
No. The Schuko plug (CEE 7/4) is not compatible with UK BS 1363 sockets, which use three square pins. A Type 2 to Schuko cable is designed for use in countries with Schuko sockets (Germany, Austria, the Netherlands, and much of continental Europe). For UK home slow charging, you need a separate granny charger with a UK three-pin plug.
Is a plain Schuko adapter safe for EV charging?
No. A bare Schuko adapter plug, the kind that simply converts one socket type to another, is not safe for EV charging. IEC 62752 requires every Mode 2 EV charging cable to include an IC-CPD: a device that monitors earth continuity, detects overcurrent, and sends a safe-to-charge pilot signal before current flows. A bare adapter has none of these protections.
What is the IC-CPD in a Schuko EV cable?
IC-CPD stands for in-cable control and protection device. It is the control box you see partway along a Mode 2 EV charging cable. Required by IEC 62752, it continuously monitors earth continuity, protects against overcurrent, and only allows charging to begin once it has confirmed a safe connection. Without an IC-CPD, the cable is not a compliant Mode 2 product.
What if my EU campsite doesn’t have Schuko sockets?
Many EU campsites use blue IEC 60309 16 A Commando hook-up points rather than Schuko sockets. Before travelling, check with your specific campsite which standard they use. Some drivers carry both a Type 2 to Schuko cable and a Type 2 to Commando cable. Our full guide to charging your EV in Europe covers campsite options in more detail.
