Hyundai EV Charging Cables & V2L

The Ioniq 5, Ioniq 6, Kona Electric and Inster all charge on the universal Type 2 (Mode 3) connector, and the Ioniq 5, Ioniq 6 and Kona Electric also support V2L, which calls for a discharge adapter rather than a charging cable. Older Hyundai plug-ins may be Type 1, so check the charge port shape first. The Hyundai cables here come in 7kW and 22kW ratings, with Mode 2 (3-pin granny) options for emergency charging.

6 productsHyundaiAll in UK stock
Hyundai EV Charging Cables for UK EV owners

Which Hyundai?

We'll preselect the variant that fits.

We read your charge port, max AC rate and phase from DVLA data, then take you to the exact variant.

6 products

Choosing the right cable for your Hyundai

Hyundai's EV range (Inster, Ioniq 5, Ioniq 6, Ioniq 9, Kona Electric) shares Kia's E-GMP 800V platform on the larger models. Native V2L across the line, Type 2 AC + CCS DC universally. The Ioniq 5 set the V2L benchmark when launched in 2021 and the rest of the range follows.

Connector spec by model

  • Inster (2025+): Type 2 + CCS. 11kW AC. V2L 3.6kW.
  • Ioniq 5 (2021+): Type 2 + CCS. 11kW AC. V2L 3.6kW. 800V (350kW DC).
  • Ioniq 6 (2023+): Type 2 + CCS. 11kW AC. V2L 3.6kW. 800V.
  • Ioniq 9 (2025+): Type 2 + CCS. 11kW AC. V2L 3.6kW. 800V.
  • Kona Electric (2018+): Type 2 + CCS. 11kW AC. V2L on second-gen Kona Electric (2024+).
  • Ioniq Electric (2017-2022): Type 2 + CCS. 7.4kW AC. No V2L.
  • Tucson PHEV: Type 2 AC, 7.4kW (32A single-phase).

V2L: what makes it useful

Every E-GMP Hyundai (Ioniq 5, 6, 9, Inster, post-2024 Kona Electric) supports V2L at 3.6kW from the Type 2 port. Plug in a V2L adapter and you have a UK 3-pin socket on the side of your car. Up to 3.6kW continuous: enough for a kettle, oven element, fridge, multiple power tools.

The Ioniq 5 ships standard with a discreet V2L cable in the boot. Ioniq 6 same. Ioniq 9 expands the V2L menu with internal cabin sockets. The Inster has the smallest battery (49kWh) so V2L runtime is shorter, maybe 6-8 hours of fridge + lights, vs 16+ hours on an Ioniq 9.

800V architecture: DC charging

Ioniq 5, 6, 9 and (selected) Kona Electric are 800V, peak ~230-250kW DC on a 350kW ultra-rapid station (Ionity, Tesla Supercharger V4, BP Pulse 300kW). 10-80% in about 18 minutes. The Inster is 400V, peaks around 85kW DC.

800V doesn't change home AC charging: caps at 11kW AC like every modern EV.

AC charging speed at home

  • 11kW three-phase: ~45 miles/hour. Refills Ioniq 5 (77kWh) overnight in 6.5 hours.
  • 7.4kW single-phase: ~25-30 miles/hour. Same Ioniq 5 in 10 hours.

Length recommendations

Hyundai charge ports are at the rear-right on Ioniq 5/6 and front-right on Inster/Kona. Pick a Type 2 cable that covers your driveway plus 1-2m slack: 7.5m or 10m for typical UK home setups.

Cable adapters

For Hyundai V2L specifically, our V2L adapter with UK 3-pin output (single or double socket) is the spec to match. Multi-socket variants split the 3.6kW total across both outlets, fine for low-draw devices, less ideal for two power-hungry tools.

Smart-tariff integration

Bluelink (Hyundai's app) does basic charge scheduling. For dynamic Octopus Intelligent integration, pair your Hyundai with Ohme; for solar-PV homes pair with MyEnergi Zappi.

Older Ioniq Electric (2017-2022)

The pre-Ioniq-5 "Ioniq Electric" hatchback caps at 7.4kW AC and doesn't have V2L. Standard Type 2 AC + CCS DC. A 7.4kW cable is the right pairing: 11kW or 22kW work but throttle.

Questions

Will this cable work with my Hyundai?
Every current UK Hyundai EV uses Type 2 (Mode 3). Older Hyundai hybrids or pre-2018 EVs may use Type 1, check your charge port: hexagonal 7-pin = Type 2, square 5-pin = Type 1.
What length cable should I get for my Hyundai?
10m suits most UK home setups. 5m if your wallbox is right next to where you park. 15-25m for awkward driveway layouts.
What rating? 7kW or 22kW?
Match to your wallbox. UK home wallboxes are mostly 7kW (32A single-phase). 22kW only relevant if you have a three-phase supply.
Do you sell granny cables for this car?
Yes: see our granny chargers range. Mode 2 portable cables work with all current Hyundai EVs.
How long does delivery take?
In-stock items ship same-day if ordered before 16:00 on a working day. Standard delivery is next-working-day across mainland UK. Northern Ireland, Channel Islands and remote Highlands take 2-3 working days. Free delivery on orders over £150.
