Hyundai Ioniq EV Charging Cables
Type 2 EV charging cable: up to 22kW, single and three-phase
- Free next-working-day delivery - order before 4pm
- 30-day returns, we pay the postage if it doesn't fit
- 2-year minimum manufacturer warranty, and we handle the claim
- UK-based support, 8am-6pm, from people who drive EVs
Overview
Two things decide which cable a Hyundai Ioniq owner actually needs: whether there is a charge point on the wall at home, and how far the car sits from it. If the Ioniq is new to you and no charging station has been installed yet, start with a Type 2 to 3-pin cable. It plugs straight into an ordinary UK domestic socket, so the car is charging the day it arrives. If a charge point is already fitted, a 32A Type 2 to Type 2 cable is the better buy. It connects directly to the unit and lets the Ioniq draw power at its best rate.
How to charge a Hyundai Ioniq
- Find the charging port. On the Ioniq it usually sits on the front left wing or the left-hand side of the car. A green light on the port illuminates once the car is plugged in.
- Open the port cover, either by pressing the button on the port or by pulling the release handle.
- Push the cable into the car's port until it is properly seated.
- Connect the other end to the charging station. Public units often ask you to swipe a card or enter a code before power flows.
- Charging begins on its own. The dashboard display shows the current status and an estimated time to full.
- The car stops charging automatically when the battery is full. Unplug at both ends and close the port cover.
How quickly does an Ioniq charge?
That depends on the charge point and on how empty the battery is. The Ioniq EV carries a 7.2 kW onboard charger, so 7.2 kW is the ceiling on AC no matter how the cable or wallbox is rated. On a home charging station, which is the most common setup, a full charge generally lands somewhere between 4 and 6 hours, stretching towards 6 to 8 hours from a low state of charge. Some later Ioniq models are fitted with a higher-powered onboard charger, which can shorten that, although it varies by model and by the equipment you plug into.
We stock both cable types in 5m, 10m, 15m and 20m, in 16A and 32A, single and three-phase, rated 3.6kW, 7.2kW or 22kW. All are built to IEC 62196-2 (Type 2), CE marked and TÜV certified, IP55 rated, drive-over resistant and good from -30°C to +60°C. Browse the full range in Type 2 charging cables, or see our granny chargers if you are charging from a three-pin socket. Every cable carries a 24 month manufacturer warranty, and UK delivery is free and next working day on orders over £150.
The rest of the Hyundai range sits on our Hyundai charging cables page.
Specifications
- Connector
- Type 2 to Type 2 / 3-Pin
- Standard
- IEC 62196-2 (Type 2 / MENNEKES), 7-pin
- Cable lengths
- 5m, 10m, 15m, 20m
- Rated power
- 2.3kW / 3.6kW / 7.2kW / 22kW
- Current
- 6–12A / 16A / 32A
- Phase
- Single & Three-phase
- Conductor
- 2.5-6mm² copper (by current rating)
- Weatherproofing
- IP55 (IP67 on Type 2 to 3-Pin)
- Operating temperature
- -30°C to +60°C
- Build
- Run-over proof (drive-over resistant)
- Certifications
- CE marked, TÜV certified, IEC 62196-2 (Type 2)
- Warranty
- 24 months (2 years) manufacturer warranty
Features
-
Run-over proof
Built to take the weight of a car, so you can drive over the cable without damaging it (protection against pressure).
-
All-weather rated
Rated IP55, with the Type 2 to 3-Pin version rated IP67, and built to operate from -30°C to +60°C, so it charges reliably through UK rain, frost and summer heat.
-
Universal Type 2 fit
Works with all Type 2 electric vehicles and every UK/EU home wallbox and public AC charge point. No brand lock-in.
-
CE / TÜV certified
Independently certified to CE and TÜV, and built to the IEC 62196-2 Type 2 connector standard.
-
3-pin option for home sockets
Choose the 3-pin version to top up from a standard UK domestic socket when there is no wallbox nearby. It is a separate cable option, not an attachment.
-
Three-phase option
Pick the 32A three-phase version to charge at up to 22kW where a three-phase supply is available. The single-phase versions charge at up to 7.2kW on a standard home wallbox.
Installation
- 01Unlock the car - most won't accept a cable while locked.
- 02Wallbox end first, then the car. Push until the latch clicks.
- 03Check the car shows a charging state before you walk away.
- 04Coil loosely into the bag - no tight figure-of-eights.
In the box
-
Charging cable
1
FAQs
Is this cable compatible with the Hyundai Ioniq?
Which cable length should I choose?
Do I need the 22kW (three-phase) option?
Can I use it at public charge points as well as at home?
What's the 3-pin option for?
Is it safe to leave outside in the rain?
What warranty and delivery do I get?
Compatibility
- Hyundai Ioniq
- All Type 2 electric vehicles (UK & EU, most post-2018)
- Charger: Ohme
- Charger: Pod Point
- Charger: Zappi
- Charger: Hypervolt
- Charger: myenergi
- Charger: Wallbox
- Charger: EO
- Charger: Andersen
- Charger: Tesla
