Ford Kuga Charging Cable
Type 2 EV charging cable: up to 22kW, single and three-phase
- Free next-working-day delivery - order before 4pm
- 30-day returns, we pay the postage if it doesn't fit
- 2-year minimum manufacturer warranty, and we handle the claim
- UK-based support, 8am-6pm, from people who drive EVs
Overview
Which length of Ford Kuga charging cable should you buy?
It depends entirely on where you charge. If the Kuga sits on your own drive with the charging station a couple of feet from the flap, a shorter cable is fine and much easier to coil. If you plan on charging in public, go longer. Bays are often occupied, badly positioned or blocked, and a longer lead lets you stretch past a space or two to reach the car rather than driving on to the next site. Our advice is to keep your options as flexible as possible: most owners find the extra few metres pays for itself the first time a bay is taken. Compare lengths in our Type 2 charging cables.
Which connector does the Kuga PHEV use?
The Ford Kuga PHEV is fitted with a Type 2 (Mennekes) inlet, the connector used for electric vehicles across Europe and the one you will find on UK home charging stations and public AC charge points. A Type 2 to Type 2 lead therefore covers you at home, at work and out on the road, with a Type 2 to 3-pin lead as a mains-socket backup.
How long does a Ford Kuga PHEV take to charge?
Charging time comes down to the size of the battery and the equipment you are using. The Kuga PHEV carries a 13.6 kWh battery, and Ford state that it can be charged in around 7.5 hours from a home or public AC charging station. Plug into an ordinary 3-pin household socket instead and the time may be significantly longer, around 20 hours or more, so treat that as the overnight-and-then-some option rather than your daily routine.
Cable specification
- Type 2 to Type 2 or Type 2 to 3-pin, IEC 62196-2, 7-pin
- 5m, 10m, 15m and 20m lengths
- 16A or 32A, 3.6kW / 7.2kW / 22kW, single and three-phase
- 2.5 to 6mm² copper conductors by current rating
- IP55, rated -30°C to +60°C, drive-over resistant
- CE marked and TÜV certified
Every cable carries a 24 month manufacturer warranty. Order before 4pm for same-day dispatch, free next-working-day UK delivery on orders over £150, and 30 days to return.
The rest of the Ford range sits on our Ford charging cables page.
Specifications
- Connector
- Type 2 to Type 2 / 3-Pin
- Standard
- IEC 62196-2 (Type 2 / MENNEKES), 7-pin
- Cable lengths
- 5m, 10m, 15m, 20m
- Rated power
- 2.3kW / 3.6kW / 7.2kW / 22kW
- Current
- 6–12A / 16A / 32A
- Phase
- Single & Three-phase
- Conductor
- 2.5-6mm² copper (by current rating)
- Weatherproofing
- IP55 (IP67 on Type 2 to 3-Pin)
- Operating temperature
- -30°C to +60°C
- Build
- Run-over proof (drive-over resistant)
- Certifications
- CE marked, TÜV certified, IEC 62196-2 (Type 2)
- Warranty
- 24 months (2 years) manufacturer warranty
Features
-
Run-over proof
Built to take the weight of a car, so you can drive over the cable without damaging it (protection against pressure).
-
All-weather rated
Rated IP55, with the Type 2 to 3-Pin version rated IP67, and built to operate from -30°C to +60°C, so it charges reliably through UK rain, frost and summer heat.
-
Universal Type 2 fit
Works with all Type 2 electric vehicles and every UK/EU home wallbox and public AC charge point. No brand lock-in.
-
CE / TÜV certified
Independently certified to CE and TÜV, and built to the IEC 62196-2 Type 2 connector standard.
-
3-pin option for home sockets
Choose the 3-pin version to top up from a standard UK domestic socket when there is no wallbox nearby. It is a separate cable option, not an attachment.
-
Three-phase option
Pick the 32A three-phase version to charge at up to 22kW where a three-phase supply is available. The single-phase versions charge at up to 7.2kW on a standard home wallbox.
Installation
- 01Unlock the car - most won't accept a cable while locked.
- 02Wallbox end first, then the car. Push until the latch clicks.
- 03Check the car shows a charging state before you walk away.
- 04Coil loosely into the bag - no tight figure-of-eights.
In the box
-
Charging cable
1
FAQs
Is this cable compatible with the Ford Kuga?
Which cable length should I choose?
Do I need the 22kW (three-phase) option?
Can I use it at public charge points as well as at home?
What's the 3-pin option for?
Is it safe to leave outside in the rain?
What warranty and delivery do I get?
Compatibility
- Ford Kuga
- All Type 2 electric vehicles (UK & EU, most post-2018)
- Charger: Ohme
- Charger: Pod Point
- Charger: Zappi
- Charger: Hypervolt
- Charger: myenergi
- Charger: Wallbox
- Charger: EO
- Charger: Andersen
- Charger: Tesla
