Every Volkswagen ID model sold in the UK — the ID.3, ID.4, ID.5, ID.7, and ID.Buzz — shares the same fundamental charging architecture: a Type 2 inlet and an 11kW three-phase onboard AC charger, standard across all trims. That consistency makes cable shopping straightforward, but there are still three decisions worth getting right: cable type (3-phase or single-phase), cable length (port position varies by model), and whether you need a granny cable at all (spoiler: you’ll need to buy one separately).
This guide covers everything you need to know, based on Volkswagen UK manufacturer onboard-charger spec sheets and our own first-party data at EV Cable Hub.
What connector does the Volkswagen ID range use?
The entire Volkswagen ID range uses a Type 2 inlet (defined by IEC 62196-2) for AC charging — home wallboxes, public slow chargers, and rapid AC posts all use this same 7-pin connector. There is nothing model-specific here: the ID.3, ID.4, ID.5, ID.7, and ID.Buzz all share the same inlet standard.
If you are new to EV charging connectors, our guide to Type 2 charging cables explains what you are buying and why Type 2 became the UK standard.
Type 2 (IEC 62196-2) — the universal standard
The Type 2 connector has seven pins arranged in a characteristic D-shape: three phase lines (L1, L2, L3), a neutral (N), a protective earth (PE), a control pilot (CP), and a proximity pilot (PP). The three-phase capability is what allows cars like the VW ID range to charge at 11kW rather than the 7.4kW ceiling of single-phase charging.
CCS for DC rapid charging
For DC rapid charging, all VW ID models use a CCS (Combined Charging System) inlet. This sits below the Type 2 socket on the car and adds two large DC pins. At a rapid charger the cable is tethered — you do not bring your own cable for DC charging. The cable you are buying for home use and public AC charging is always the Type 2 cable described in this guide.
How much AC power can a VW ID actually accept?
This is where many VW ID owners get caught out — not by the car, but by the cable.
According to Volkswagen UK manufacturer onboard-charger spec sheets, all MEB-platform ID models are fitted with an 11kW three-phase onboard AC charger as standard. That applies to every trim level, including base variants. There is no optional upgrade and no higher specification to unlock — 11kW is simply what the platform delivers.
What this means in practice: to reach 11kW at a compatible wallbox or public post, you need both a three-phase supply and a 3-phase (5-pin) Type 2 cable. If either element is single-phase, the delivered power drops.
11kW three-phase across all models — no upspec needed
The MEB (Modularer E-Antriebs-Baukasten) platform is the shared architecture underpinning the ID.3, ID.4, ID.5, ID.7, and ID.Buzz. Because onboard AC charging hardware is baked into the platform rather than specified per model, the 11kW three-phase capability is identical across the range.
This is a meaningful piece of information that many buying guides omit: you do not need to step up to a higher trim or pay for an optional charging package to get 11kW. Every current UK-spec VW ID does it.
Why a single-phase cable caps you at 7.4kW even on a 22kW post
Here is the mechanism that catches people out. When you plug a single-phase Type 2 cable into your VW ID, the car’s onboard charger only engages one phase — because that is all the cable can carry. Result: 7.4kW maximum, regardless of what the wallbox or public post is rated at.
A 22kW public post is three-phase. But if your cable is single-phase, you still receive 7.4kW. The post’s three-phase capacity is simply unavailable to you.
Flip the scenario: a 3-phase cable on a single-phase wallbox delivers 7.4kW — not 11kW, because the supply is single-phase. The cable is not limiting you here; the supply is. The cable is simply ready when your supply catches up.
Our 7kW vs 22kW cable guide goes deeper into how onboard charger ratings interact with post capacity and cable phase.
Which VW ID model has which charge port position?
All five models share the same charging standard, but the physical position of the charge port differs — and that directly affects which cable length you should buy.
| Model | Charge port position | Onboard AC | Recommended cable |
|---|---|---|---|
| ID.3 | Driver-side rear | 11kW | 5m (7m if wallbox on opposite side) |
| ID.4 | Centre rear | 11kW | 5m |
| ID.5 | Centre rear | 11kW | 5m |
| ID.7 | Rear | 11kW | 5m |
| ID.Buzz | Rear-left | 11kW | 7m recommended |
ID.3 — driver-side rear
The ID.3’s charge port sits at the rear on the driver’s side. For most UK driveways where the wallbox is on the driver’s side, a 5-metre cable reaches without fuss. If your wallbox is on the opposite side — or you park nose-in when the wallbox is at the rear — allow for 7 metres.
ID.4 and ID.5 — centre rear
The ID.4 and ID.5 share a centre-rear charge port, which gives the most consistent cable run regardless of which side the wallbox is on. Five metres is usually sufficient. The ID.5’s coupe-style roofline does not affect port position.
ID.7 — rear
The ID.7’s port is at the rear. Being a larger saloon, there is more car to accommodate, but 5 metres covers the typical driveway run comfortably. If your wallbox is mounted at the front of your garage and you reverse in, measure the full run before ordering.
ID.Buzz — rear-left
The ID.Buzz deserves a special mention. As the newest and largest addition to the MEB family — a proper people carrier with a correspondingly larger battery — the Buzz’s charge port is at the rear-left. Its size means the cable run from a wallbox on the right side of a driveway is longer than you might expect. We suggest treating 7 metres as the default for ID.Buzz owners rather than 5.
What cable length do I need for my Volkswagen ID?
The simple answer is 5 metres for most VW ID drivers, and 7 metres if your setup has any of the following: an ID.Buzz, a wallbox mounted on the far side of your driveway, a garage where you park nose-in, or a charge port that faces away from the wallbox.
Our cable length guide walks through how to measure your own driveway run properly, which is always the most reliable approach over a rule of thumb.
What we see from our own customer data at EV Cable Hub is that ordering too short is the most common cable regret — particularly among ID.3 owners who have a wallbox on the passenger side. Five metres looks generous on paper and occasionally falls short in practice. When in doubt, 7 metres.
Does a new Volkswagen ID come with a charging cable?
Granny cable (Mode 2) — not supplied as standard in 2025/26
This is one of the clearest gaps between buyer expectation and reality. As of 2025–26, Volkswagen does not include a Mode 2 granny cable (IEC 62752) with new VW ID models in the UK. It is not in the boot, not in the charging kit, and not a dealer-fitted default. If you drive your new ID home and plug a household 3-pin socket into the wall, you will be searching for a cable you do not have.
A granny cable connects the Type 2 inlet on the car to a standard 13A domestic socket using Mode 2 safety electronics. It charges slowly — around 1.8–2.3kW — but it is genuinely useful as a backup when a wallbox or public charger is not available. You will need to buy one separately.
What to look for if you’re buying used
Used VW ID models sold privately or through non-VW channels may or may not include a granny cable. It is worth asking explicitly during any used purchase, as it is a £50–£150 item to replace. A Type 2 untethered cable for public charging is a separate item entirely and is almost never included with used sales.
VW ID charging cable: our recommendation
Buy a 3-phase (5-pin) Type 2 cable, either 5m or 7m depending on your driveway layout. Here is why:
- All VW ID models have an 11kW three-phase onboard charger. A 3-phase cable is the only way to access it fully.
- On a single-phase supply, a 3-phase cable delivers 7.4kW — identical to what a single-phase cable would give you. There is no penalty for owning a 3-phase cable on a single-phase installation.
- If you ever install a three-phase supply, upgrade your wallbox, or charge at a 22kW public post, a 3-phase cable is already future-proofed. A single-phase cable permanently caps you at 7.4kW in those situations.
The only scenario where a single-phase cable makes sense is if you are entirely certain you will never use a three-phase supply and want to save a small amount on the cable purchase. For most VW ID owners, that trade-off does not make sense.
Length recommendation summary: - ID.3: 5m as default; 7m if wallbox is on the passenger side or awkward position - ID.4, ID.5, ID.7: 5m suits most setups - ID.Buzz: 7m as default given port position and vehicle size
We have drawn on EV Cable Hub first-party data — including customer support queries and return reasons — in forming these recommendations. The most common return we see is a 5m cable that did not quite reach, particularly for ID.Buzz owners.
Frequently asked questions
What Type 2 cable does a VW ID.3 need?
The ID.3 uses a standard Type 2 (IEC 62196-2) cable for AC charging. We recommend a 3-phase (5-pin) Type 2 cable to access the car’s full 11kW onboard charger. A 5-metre cable suits most driveways; choose 7 metres if the wallbox is on the opposite side from the driver-side rear port.
Do all VW ID models charge at 11kW?
Yes. All current UK-spec VW ID models — ID.3, ID.4, ID.5, ID.7, and ID.Buzz — come with an 11kW three-phase onboard AC charger as standard across all trim levels. No upgrade or optional extra is needed to access 11kW.
Does a new VW ID come with a charging cable?
No. As of 2025–26, Volkswagen does not include a Mode 2 granny cable or a Type 2 cable with new ID models in the UK. You need to purchase a Type 2 cable separately before you can charge at home or at a public AC point.
Can I use a single-phase Type 2 cable on my VW ID?
Yes, it will work — but it caps your charge speed at 7.4kW regardless of the post’s capacity. Because all VW ID models have a three-phase onboard charger, a 3-phase cable unlocks the full 11kW. A single-phase cable leaves 3.6kW unused, even in front of a 22kW public charger.
What length charging cable do I need for a VW ID.Buzz?
The ID.Buzz charge port is at the rear-left. If your wallbox is on the right side of your driveway or garage, the cable must travel around the back of the vehicle. A 7-metre cable is the safer choice for the ID.Buzz; 5 metres may fall short in awkward layouts.
What is the difference between CCS and Type 2 on a VW ID?
They serve different functions. The Type 2 inlet (AC) is used for home charging and standard public AC charging with a Type 2 cable. The CCS inlet (DC) is the rapid-charge port used at fast-charge stations — the cable is tethered at the rapid charger, so you do not need to bring your own.
Will a 3-phase Type 2 cable work on a single-phase home wallbox?
Yes. A 3-phase (5-pin) Type 2 cable is fully compatible with single-phase supplies and wallboxes. On a single-phase supply it delivers 7.4kW — the same as a single-phase cable. The advantage is future-proofing: if you upgrade to a three-phase supply or use a 22kW public post, the cable already supports full 11kW delivery without any change.
