3.6kW (16A Single-Phase) EV Charging Cables

3.6kW (16A single-phase) is the entry-level Mode 3 cable, and it suits older PHEVs, plug-in hybrids, and budget wallboxes capped at 16 amps. Expect around 12-15 miles of range per hour on a typical EV. It also runs cooler than a 32A cable, which can extend cable life if you charge daily on a 16A wallbox.

Most modern UK EVs and wallboxes are spec'd for 7.4kW (32A), and our 7.4kW range covers those. A 32A cable will work on a 16A wallbox, you will simply have paid for headroom you cannot use. Check your wallbox spec before ordering. 2-year warranty, free UK delivery over £150.

216 productsAll in UK stock
3.6kW (16A Single-Phase) Charging Cables for UK EV owners

Which car is it?

We'll preselect the variant that fits.

We read your charge port, max AC rate and phase from DVLA data, then take you to the exact variant.

216 products

Matching cable power to wallbox and supply

A 3.6kW EV charging cable is the entry-level Mode 3 cable, 16A single-phase, charging at about 13-14 miles of range per hour. It's slower than the 7.4kW cables most UK home wallboxes use, but there are real reasons buyers choose it: low-current public chargers, caravan-park hook-ups, older cars that cap their AC at 3.6kW, and budget-conscious second cables.

What "3.6kW" really means

EV cables don't generate power: they carry it from the source to the car. A 3.6kW (16A) rating describes the cable's maximum current capacity. The actual charging speed is determined by the lowest of three things: the source's output, the cable's rating, the car's onboard AC charger limit. So:

  • 16A wallbox + 16A cable + 7kW car = charges at 16A (3.6kW). Cable is the bottleneck.
  • 32A wallbox + 16A cable + 7kW car = charges at 16A (3.6kW). Cable is the bottleneck.
  • 32A wallbox + 32A cable + 16A car = charges at 16A (3.6kW). Car is the bottleneck.

When 3.6kW is the right choice

  • Caravan and motorhome charging: sites typically offer 16A blue Commando hook-ups; a 3.6kW Type 2 cable matches the supply.
  • Older EVs with a 3.6kW onboard limit: first-gen Nissan Leaf, original Outlander PHEV, some early Renault Zoes. A 7.4kW cable is wasted on these cars.
  • Backup / second cable: kept in the boot at lower cost than a full 7.4kW cable. Light, compact, fits in a small bag.
  • Some workplace and apartment AC chargers are 16A only, especially older Pod Point and BP Pulse public installs from 2017-2019.

When 3.6kW is the wrong choice

If you're buying a primary cable for daily home charging on a 7kW wallbox, a 7.4kW cable doubles your charging speed and only costs marginally more. The maths: 7.4kW adds 25-30 miles per hour; 3.6kW adds 13-14. For a typical 60kWh battery, 3.6kW takes 16 hours from empty; 7.4kW takes 8 hours. If you charge daily at home, 7.4kW is almost always the right answer.

Connector type and length

Most 3.6kW cables are Type 2 to Type 2 (UK and European standard). Type 1 to Type 2 3.6kW cables exist for older Leafs and similar, see the Type 1 to Type 2 collection. Lengths from 5m through to 15m are widely available; 5m is most common, 7m or 10m offers more flexibility.

3.6kW vs granny charger: what's the difference?

Both deliver about 3kW. The difference is the source-end connector:

  • Granny charger: UK 3-pin domestic plug → Type 2. For household sockets only.
  • 3.6kW Mode 3 cable: Type 2 → Type 2. For wallboxes and public AC chargers only.

A granny charger plugs into the wall; a 3.6kW Mode 3 cable plugs into a Type 2 socket. They're not interchangeable.

Build quality at the budget end

3.6kW cables are often the cheapest in the catalogue, but cheap doesn't have to mean unsafe. Hold the line on:

  • IEC 62196-2 certified Type 2 connectors: non-negotiable for any UK Mode 3 cable.
  • IP44 weatherproofing minimum.
  • OFC copper, not CCA: copper-clad aluminium cables run hot and degrade.
  • 2-year UK warranty minimum from a UK retailer.

Related

Questions

Will my wallbox use the full speed of this cable?
Only if the wallbox is rated equal or higher. A 32A cable on a 16A wallbox throttles to 16A. Check your wallbox spec: most UK home wallboxes are 32A (7kW) or 32A three-phase (22kW).
Do I have a three-phase supply?
Most UK domestic supplies are single-phase. If you're not sure, check your distribution board or ask a qualified electrician. Single-phase = one live wire; three-phase = three live wires (typically only newer or larger UK builds).
Will a higher-power cable damage my car?
No. The car requests current from the cable based on what it can accept. A 32A cable on a car that asks for 16A simply delivers 16A.
How long does delivery take?
In-stock items ship same-day if ordered before 16:00 on a working day. Standard delivery is next-working-day across mainland UK. Northern Ireland, Channel Islands and remote Highlands take 2-3 working days. Free delivery on orders over £150.
What warranty do these come with?
Every product on our shelf carries a minimum two-year manufacturer warranty. We administer warranty claims directly: ship the replacement next-day and collect the original at no cost to you.
